Baja Designs OnX6 Straight Racer Edition LED Light Bar - Universal


Select Light Pattern: Racer Spot
Select Lens Color: Clear
Select Size: 10"
Price:
Sale price$599.95
Stock:
In stock

All Baja Designs LED products (except RTL and SAE) are experiencing 4-6 week average lead times. We are shipping orders as quickly as possible.

The biggest in our Racer Edition line, the 50-inch OnX6 Racer Edition Light Bar also packs the hardest punch. If you have enough room to mount it, the 50-inch OnX6 Racer Edition Light Bar delivers all the power you need for high-speed nighttime driving, either on-road or off. The 50-inch OnX6 Racer Edition Light Bar was engineered for speeds of 110 plus MPH, and it comes with our industry-first 30-day Satisfaction Guarantee and Limited Lifetime Warranty. The OnX6 Racer Edition LED Light Bar is BRIGHTER, BOLDER, BETTER.

  • Satisfaction Guarantee – 30-Day Money Back Guarantee
  • Limited Lifetime Warranty – Complete Purchase Protection
  • uService – Replaceable Lenses And Optics
  • ClearView – All The Light, Right Where You Need It
  • MoistureBlock – Waterproof, Rain Proof, Submersible
  • CopperDrive – Only LED Driven At 100 Percent
  • 5000K Daylight – Less Driver Fatigue, Natural Color

SKU: 411002

Dimensions

Depth (in.) 4.29
Height (in.) 2.69
Length (in.) 10
Weight (lbs.) 4.25

Specifications

Amperage Rating (A) 5.25
Average Rated Life (hr.) 49,930
Beam Pattern Racer Spot
Bezel Material Billet Machined Aluminum
Description Straight; Racer Spot; Clear
Housing Color Black
Housing Material Aircraft Grade Aluminum with Mil-Spec Hard Anodize
Lens Color Clear
Lighting Modes Hardcoated Polycarbonate
Light Quantity 1
Lens Material Beam
Lighting Quantity 6
Lighting Type LED
Lighting Technology Forward Projecting
Mounting Hardware Description Mounting Brackets
Mounting Hardware Included Yes
Mounting Hardware Material Stainless Steel
Overvoltage Protection Built-In
Product Type OnX6+ 10 Inch Racer Edition LED Light Bar
Universal or Specific Universal
Wattage (W) 63
Wiring Harness Included No

Standards & Compliance

Standards/Compliance (Durability) Exceeds MIL-STD810G (Mil-Spec Testing)
Standards/Compliance (Water Resistance) IK10 Compliant (Mechanical Impact Testing)
Standards/Compliance (Impact Resistance) IP69K (Waterproof up to 9ft & Pressure Washable)

SKU: 412002

Dimensions

Depth (in.) 4.29
Height (in.) 2.69
Length (in.) 20
Weight (lbs.) 7.85

Specifications

Amperage Rating (A) 10.5
Average Rated Life (hr.) 49,930
Beam Pattern Racer Spot
Bezel Material Billet Machined Aluminum
Description Straight; Racer Spot; Clear
Housing Color Black
Housing Material Aircraft Grade Aluminum with Mil-Spec Hard Anodize
Lens Color Clear
Lighting Modes Hardcoated Polycarbonate
Light Quantity 1
Lens Material Beam
Lighting Quantity 12
Lighting Type LED
Lighting Technology Forward Projecting
Mounting Hardware Description Mounting Brackets
Mounting Hardware Included Yes
Mounting Hardware Material Stainless Steel
Overvoltage Protection Built-In
Product Type OnX6+ 20 Inch Racer Edition LED Light Bar
Universal or Specific Universal
Wattage (W) 126
Wiring Harness Included No

Standards & Compliance

Standards/Compliance (Durability) Exceeds MIL-STD810G (Mil-Spec Testing)
Standards/Compliance (Water Resistance) IK10 Compliant (Mechanical Impact Testing)
Standards/Compliance (Impact Resistance) IP69K (Waterproof up to 9ft & Pressure Washable)

SKU: 413002

Dimensions

Depth (in.) 4.29
Height (in.) 2.69
Length (in.) 30
Weight (lbs.) 11.45

Specifications

Amperage Rating (A) 15.75
Average Rated Life (hr.) 49,930
Beam Pattern Racer Spot
Bezel Material Billet Machined Aluminum
Description Straight; Racer Spot; Clear
Housing Color Black
Housing Material Aircraft Grade Aluminum with Mil-Spec Hard Anodize
Lens Color Clear
Lighting Modes Hardcoated Polycarbonate
Light Quantity 1
Lens Material Beam
Lighting Quantity 18
Lighting Type LED
Lighting Technology Forward Projecting
Mounting Hardware Description Mounting Brackets
Mounting Hardware Included Yes
Mounting Hardware Material Stainless Steel
Overvoltage Protection Built-In
Product Type OnX6+ 30 Inch Racer Edition LED Light Bar
Universal or Specific Universal
Wattage (W) 189
Wiring Harness Included No

Standards & Compliance

Standards/Compliance (Durability) Exceeds MIL-STD810G (Mil-Spec Testing)
Standards/Compliance (Water Resistance) IK10 Compliant (Mechanical Impact Testing)
Standards/Compliance (Impact Resistance) IP69K (Waterproof up to 9ft & Pressure Washable)

SKU: 414002

Dimensions

Depth (in.) 4.29
Height (in.) 2.69
Length (in.) 40
Weight (lbs.) 15.05

Specifications

Amperage Rating (A) 21
Average Rated Life (hr.) 49,930
Beam Pattern Racer Spot
Bezel Material Billet Machined Aluminum
Description Straight; Racer Spot; Clear
Housing Color Black
Housing Material Aircraft Grade Aluminum with Mil-Spec Hard Anodize
Lens Color Clear
Lighting Modes Hardcoated Polycarbonate
Light Quantity 1
Lens Material Beam
Lighting Quantity 24
Lighting Type LED
Lighting Technology Forward Projecting
Mounting Hardware Description Mounting Brackets
Mounting Hardware Included Yes
Mounting Hardware Material Stainless Steel
Overvoltage Protection Built-In
Product Type OnX6+ 40 Inch Racer Edition LED Light Bar
Universal or Specific Universal
Wattage (W) 252
Wiring Harness Included No

Standards & Compliance

Standards/Compliance (Durability) Exceeds MIL-STD810G (Mil-Spec Testing)
Standards/Compliance (Water Resistance) IK10 Compliant (Mechanical Impact Testing)
Standards/Compliance (Impact Resistance) IP69K (Waterproof up to 9ft & Pressure Washable)

SKU: 415002

Dimensions

Depth (in.) 4.29
Height (in.) 2.69
Length (in.) 50
Weight (lbs.) 18.65

Specifications

Amperage Rating (A) 26.25
Average Rated Life (hr.) 49,930
Beam Pattern Racer Spot
Bezel Material Billet Machined Aluminum
Description Straight; Racer Spot; Clear
Housing Color Black
Housing Material Aircraft Grade Aluminum with Mil-Spec Hard Anodize
Lens Color Clear
Lighting Modes Hardcoated Polycarbonate
Light Quantity 1
Lens Material Beam
Lighting Quantity 30
Lighting Type LED
Lighting Technology Forward Projecting
Mounting Hardware Description Mounting Brackets
Mounting Hardware Included Yes
Mounting Hardware Material Stainless Steel
Overvoltage Protection Built-In
Product Type OnX6+ 50 Inch Racer Edition LED Light Bar
Universal or Specific Universal
Wattage (W) 315
Wiring Harness Included No

Standards & Compliance

Standards/Compliance (Durability) Exceeds MIL-STD810G (Mil-Spec Testing)
Standards/Compliance (Water Resistance) IK10 Compliant (Mechanical Impact Testing)
Standards/Compliance (Impact Resistance) IP69K (Waterproof up to 9ft & Pressure Washable)
